Therma DM500

Product Description

THERMA DM500 is a photosensitive material developed for the manufacture of molds for injection of plastic materials.

The injected polymer can reach a maximum temperature of 200 °C with a closing pressure of up to 90 bar.

Material for manufacturing of plastic injection molds; Resistant to injection temperatures up to 200 °C.

Industries

Educational Fashion & accessories Footwear

Areas of Applications

Molding Production

Main Features

• Smooth surfaces
• High Resolution
• Precision
• High accuracy

Technical Data

Technical characteristics of the liquid material

Environmental Values for Use 22°C - 27°C - max, RH 40% - 60%

Appearance / Colour Liquid / Light Grey

Density 1,15 g/cm³

Viscosity 2000 ~ 3000 mPa•s at 25°C

Technical characteristics of the resin after UV curing

Elongation (%) —

Elongation at Break (%) 5 ~ 10

Elastic module (MPa) —

Shore Hardness (Shore A) —

Shore Hardness (Shore D) 90 ~ 91

Flexural Strength (MPa) 70 ~ 160

Flexural Modulus (MPa) 1700 ~ 4000

Tensile Strength (MPa) 50 ~ 80

Tensile Modulus (MPa) 2400 ~ 3050

HDT@0,46MPa 55 ~ 90

HDT@1,81MPa —

Notched IZOD (J/m) —

H2O absorption in 24h (%) —

Application / Use Injection Moulding
